LIGHT CURTAIN RECEIVERCML720i-R40-2210.A/CN-M12" ID:50119685| Hàng rào điện tử | Light Curtain Senso
ID:50119685
Leuze Vietnam | Greentech Vietnam
.
Basic data Series 720 Operating principle Throughbeam principle Device type Receiver Contains 2x BT-NC sliding block Application Object measurement Special design Special design Crossed-beam scanning Diagonal-beam scanning Parallel-beam scanning Optical data Operating range Guaranteed operating range Operating range 0.3 ... 7 m Operating range limit Typical operating range Operating range limit 0.2 ... 9 m Measurement field length 2,210 mm Number of beams 55 Piece(s) Beam spacing 40 mm Measurement data Minimum object diameter 50 mm Electrical data Protective circuit Polarity reversal protection Short circuit protected Transient protection Performance data Supply voltage UB 18 ... 30 V , DC Residual ripple 0 ... 15 % , From UB Open-circuit current 0 ... 435 mA , The specified values refer to the entire package consisting of transmitter and receiver. Inputs/outputs selectable Output current, max. 100 mA Input resistance 6,000 Ω Number of inputs/outputs selectable 2 Piece(s) Type Inputs/outputs selectable Voltage type, outputs DC Switching voltage, outputs Typ. UB / 0 V Voltage type, inputs DC Switching voltage, inputs high: ≥6V low: ≤4V Input/output 1 Activation/disable delay 1 ms Timing Readiness delay 450 ms Cycle time 2.05 ms Response time per beam 30 µs
