3002006 | Slipring | 3002006 | Vành trượt điện khí nén 3002006 | Senring Vietnam
3002006 | Slipring |
Senring Vietnam | Greentech Vietnam
12 tháng
.
3002006 Series Two Passages Rotary Unions
Senring two passages rotary unions 3002006 series,support G1/8 port for 6~8mm pipes,can transfer various mediums including compressed air, steam, vacuum,liquid...etc. when 360° rotating, Advantages : compact size, light weight , low torque, each channel works independently without mixture. It also can combine to transmit 6 to 56 circuits of electrical power and signal. 3002006 series are widely appplied in industrial equipments such as printing machine,machining equipment,packing machines ...etc
- Features
- Support transmit mixed power and signals,such as USB,HDMI, 1000M ethernet, VGA, DVI, coaxial RF (high frequency),servo motor signal,industrial bus slip rings...etc;
- 360° transmit compressed air,steam,vacuum,negative pressure,positive pressure,cooling water,hot oil...etc;
- Max. Pressure(s):1Mpa (vacuum: -1.5kPa, higher Pressure can be customized)；
- Support 2 G1/8" port for 6~8mm pipes;
- Product Manual
- 3D model
- Installation
- @Technical Inquiry
| Model | Passages(Gas/Flow) | Port Size | Pipe Size |
| 3002006 | 2 passages | G1/8" | 6~8mm |
| Model | Passages(Gas/Flow) | Port Size | Pipe Size | Signal Circuits(2A) | Length L(mm) |
| 3002006-06S | 2 passages | G1/8" | 6~8mm | 6 | 14 |
| 3002006-12S | 2 passages | G1/8" | 6~8mm | 12 | 21 |
| 3002006-24S | 2 passages | G1/8" | 6~8mm | 24 | 35 |
| 3002006-36S | 2 passages | G1/8" | 6~8mm | 36 | 52.3 |
| 3002006-56S | 2 passages | G1/8" | 6~8mm | 56 | 82 |
| Model | Passages(Gas/Flow) | Port Size | Pipe Size | Power Circuits(10A) | Signal Circuits(2A) | Length L(mm) |
| 3002006-06S | 2 Passages | G1/8" | 6~8mm | 0 | 6 | 38 |
| 3002006-0610 | 2 Passages | G1/8" | 6~8mm | 6 | 0 | 38 |
| 3002006-12S | 2 Passages | G1/8" | 6~8mm | 0 | 12 | 55 |
| 3002006-0610-06S | 2 Passages | G1/8" | 6~8mm | 6 | 6 | 55 |
| 3002006-1210 | 2 Passages | G1/8" | 6~8mm | 12 | 0 | 55 |
| 3002006-0610-12S | 2 Passages | G1/8" | 6~8mm | 6 | 12 | 71.5 |
| 3002006-1210-06S | 2 Passages | G1/8" | 6~8mm | 12 | 6 | 71.5 |
| 3002006-18S | 2 Passages | G1/8" | 6~8mm | 0 | 18 | 71.5 |
| 3002006-1810 | 2 Passages | G1/8" | 6~8mm | 18 | 0 | 71.5 |
| 3002006-0610-18S | 2 Passages | G1/8" | 6~8mm | 6 | 18 | 88.5 |
| 3002006-24S | 2 Passages | G1/8" | 6~8mm | 0 | 24 | 88.5 |
| 3002006-30S | 2 Passages | G1/8" | 6~8mm | 0 | 30 | 106 |
| 3002006-36S | 2 Passages | G1/8" | 6~8mm | 0 | 36 | 125 |
| Rotary Unions & Joints Spec. | ||||
| Passages(Gas/Flow) | 2 passages | Max. Operating Pressure | Positive Pressure 1Mpa, Vacuum -1.5kPa | |
| Pipe Size | 6~8mm pipe, G1/8" Port | torque | <0.2N.m | |
| Mechanical Data | Electrical Data | |||
| spec. | data | spec. | data | |
| Working life | 20millions for ref(depends on working conditions) | Power | Signal | |
| Max. Operating Speed | 250RPM continously, 1000RPM intermittently | Voltage range | 0~440VAC/VDC | 0~440VAC/VDC |
| Working temp. | -30°C~80°C | Insolution resistance | <500MΩ/300VDC | <500MΩ/300VDC |
| Work humidity | 0~85% RH | Lead wire spec. | AWG17# Silver-plated teflon wire | AWG22# Silver-plated teflon wire |
| Contact Materia | Precious Metal | Lead wire length | standard 250mm（can be customized） | |
| Housing Material | aluminum alloy | Insolution resistance | 500VAC@50Hz,6s | |
| IP Grade | IP51 | Electrical noise | <0.01Ω | |
| ring no. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
| color | black | brown | red | orange | yellow | green | blue | purple | grey | white | pink | lightblue |
SNFO series fiber optic slip ring（optic-electrical rotary joint）
- Produced by Senring developed Fiber optic rotary joint also called optic-electrical slip ring, using fiber for transmitting, which provides the best solution for the data transmitting of rotary connections systems. is suitable for application which needs transmitting large datas or signals from static device to rotary position when continuous or intermittent rotating. optic electrical rotary joint could improve mechanical performance, simplify operation and avoid the damage due to rotating. It is optional together with traditional slip ring to transmit power and high speed data. Relying on strong R&D ability and experienced engineers, Senring developed Optic-electrical slip ring successfully, with reliabe performance, excellent quality and 360° any direction of rotation
- Transmitting power,control signal power,and micro electrical signals from instrument,control automatic of computer
- Transmitting fiber signal type signal-mode or multi-mode, and more circuits options
- Optic-electric slip ring can be make customized followed customer's request
- Combined optic together with traditional slip ring to transmit power and high speed data
| Model# | Fiber channel | Wavelength | Combined for power and signal | Max Speed | More | |
| 1 channel | 1310nm/1550nm | -- | 2000RPM | |||
| 1 channel | 1310nm/1550nm | 1~72 | 250RPM | |||
| 2 channel | 1310nm/850nm | -- | 250RPM | |||
| 2 channel | 1310nm/850nm | 1~36 | 250RPM | |||
| 4 channel | 1310nm/850n | -- | 250RPM | |||
| 4 channel | 1310nm/850n | 1~36 | 250RPM | |||
| 6 channels | 850nm/1310nm | 1~36 | 300RPM | |||
| 8 channels | 850nm/1310nm | 1~36 | 300RPM | |||
| 8 channels | 850nm/1310nm | 1~36 | 300RPM | |||
| 6 channels | 850nm/1310nm | 1~36 | 300RPM |
Mercury slip ring A series (mercury rotary joint)
- Anti-interference, low cost
- Contact resistance is less than the 1mΩ
- No maintenance, better reliability than traditional slip ring
- Suitable for signal and power transmitting of any rotating devices
- Mercury slip ring is used with special sealing materials,insulation and conductive technology production
- Housing material is made of aluminum alloy or stainless steel
- Applied for any rotating objects of signal transmitting such as：tiny voltage¤t,EMF,thermocouple,strain gauge,audio and video signals, high frequency,computer signal and electric power connections；
| Model# | Poles | Current(A)/Poles | Dielectric Strength AC/DCAC/DC(V) | Max Frequency(MHZ) | Contact Resistance | Max Speed | Work Temperature Max/Min ℃ | Torque (x10-3Nm) | Insulation Resistance | |
| 1 pole | 250 | -- | 200 | <1mΩ | 1200 | -29℃~60℃ | 250 | -- | ||
| 1 pole | 350 | -- | 200 | <1mΩ | 800 | -29℃~60℃ | 300 | -- | ||
| 1 pole | 250 | -- | 200 | <1mΩ | 1200 | -29℃~60℃ | 250 | -- | ||
| 1 pole | 650 | -- | 200 | <1mΩ | 200 | -29℃~60℃ | 1000 | -- | ||
| 1 pole | 1500 | -- | 200 | <1mΩ | 100 | -29℃~60℃ | 2000 | -- | ||
| 2 pole | 30A | 250 | 200 | <1mΩ | 1800 | -29℃~60℃ | 200 | >25MΩ | ||
| 3 pole | 30A | 250 | 200 | <1mΩ | 1200 | -29℃~60℃ | 400 | >25MΩ | ||
| 4 pole | 30A/4 | 250 | 200 | <1mΩ | 1200 | -29℃~60℃ | 400 | >25MΩ | ||
| 6 pole | 30A/4 | 30A/4 | 100 | <1mΩ | 300 | -29℃~60℃ | 700 | >25MΩ | ||
| 8 pole | 30A/6 | 250 | 100 | <1mΩ | 200 | -29℃~60℃ | 1000 | >25MΩ | ||
| 10 pole | 30A/8 | 250 | 100 | <1mΩ | 100 | -29℃~60℃ | 1500 | >25MΩ | ||
| 12 pole | 30A/10 | 250 | 100 | <1mΩ | 60 | -29℃~60℃ | 2000 | >25MΩ | ||
| 1 pole | 10A | -- | 200 | <1mΩ | 3600 | -29℃~60℃ | 35 | >25MΩ | ||
| 1 pole | 20A | -- | 200 | <1mΩ | 2000 | -29℃~60℃ | 50 | -- | ||
| 1 pole | 50A | -- | 200 | <1mΩ | 1800 | -29℃~60℃ | 70 | -- | ||
| 2 pole | 4A | 250 | 200 | <1mΩ | 2000 | -29℃~60℃ | 75 | >25MΩ | ||
| 3 pole | 4A | 250 | 200 | <1mΩ | 1800 | -29℃~60℃ | 100 | >25MΩ | ||
| 4 pole | 30A | 250 | 100 | <1mΩ | 100 | -29℃~60℃ | 2000 | >25MΩ
|
a
SNQ series（pneumatic，hydraulic-Electrical slip rings/rotary joints）
- Senring electronics developed the production of SNQ series（pneumatic，hydraulic-Electrical slip rings/rotary joints）can be rotated 360 degrees while Transmit power,control signal,switch signal,micro signal+fiber+mercury+servo motor signal of instruments and computer automatic control
- Transmit hydraulic,more channels optional
- 1、2、3、4、6、8、12 channnels optional
- 360°transmit compressed air,negative pressure,positive pressure,cooling water,hot oil
- 360-degree video signal even HD signal transmission
- Through bore or solid optional
- Main applications:high-tech auto-equipments,packing machine
- 50% Ethernet slip rings are customized；
| Model# | Pneumatic/Hydraulic@channels | Elctric@ Circuits | tube siz | |
| 1 channel | 1~96 | 4mm-50mm | ||
| 2 channel | 1~96 | 4mm-25mm | ||
| 3 channel | 1~96 | 4mm-25mm | ||
| 4 channel | 1~48 | 4mm-25mm | ||
| 6 channel | 1~48 | 4mm-15mm | ||
| 8 channel | 1~48 | 4mm-10mm | ||
| 12 channel | 1~48 | 4mm-8mm |
