AKS 32R | Relative pressure transmitter | Máy phát áp suất tương đối | Danfoss Vietnam

(0 đánh giá)

AKS 32R

Danfoss Vietnam | Greentech Vietnam

12 tháng

AKS 32R | Relative pressure transmitter | Máy phát áp suất tương đối | Danfoss Vietnam

CHARACTERISTICS

Pressure type
relative
Technology
membrane
Output
ratiometric
Protection level
IP65, ATEX, rugged
Other characteristics
male
Applications
for refrigeration circuits, process
Process temperature

Min.: -40 °C (-40 °F)

Max.: 85 °C (185 °F)

Pressure range

Min.: 0 bar (0 psi)

Max.: 34 bar (493.13 psi)

DESCRIPTION

Pressure connection size: 7/16-20, Pressure connection type: UNF, Electrical connection size: 4 pin, Electrical connection: DIN-plug Gross weight 0.14 kg Net weight 0.12 kg EAN 5702422113218 + output Pin 3 + supply Pin 1 - common Pin 2 Accuracy, max. +/- FS [ 0.8 % Accuracy, typical +/- FS [ 0.3 % Adj. zero point and span No Ambient temperature range [°C] [Max] 85 °C Ambient temperature range [°C] [Min] -40 °C Ambient temperature range [°F] [Max] 185 °F Ambient temperature range [°F] [Min] -40 °F Approval ATEX C UR CSA GOST POCC Approval comments ATEX Ex nA IIA T3 Gc Approval standard 6967179 E227388 E31024 Compensated temp. range [°C] [Max] 80 °C Compensated temp. range [°C] [Min] 0 °C Compensated temp. range [°F] [Max] 176 °F Compensated temp. range [°F] [Min] 32 °F Electrical conn. Male/Female Male Electrical connection DIN-plug Electrical connection size 4 pin Electrical connection standard EN 175301-803-A Enclosure rating IP IP65 Flush diaphragm No High Clipping Level 98 Identical product 060G4254 Intrinsically safe No Low Clipping Level 4 Medium temperature range [°C] [Max] 85 °C Medium temperature range [°C] [Min] -40 °C Medium temperature range [°F] [Max] 185 °F Medium temperature range [°F] [Min] -40 °F Non-linearity BFSL ±FS [ 0.2 % Overload pressure max. [bar] 55 bar Packing format Multi pack Pressure connection notes Flare 1/4 in Pressure connection size 7/16-20 Pressure connection standard ASME B1.1 Pressure connection type UNF Pressure Male/Female Male Pressure range [bar] [Max] 34 bar Pressure range [bar] [Min] -1 bar Pressure range [psi] [Max] 493.13 psi Pressure range [psi] [Min] -14.5 psi Pressure unit reference Gauge (relative)
