DFS60E-BZAA0-S01 | Sick | DFS60E-BZAA0-S01 | Encoder DFS60E-BZAA0-S01| Sick Vietnam
DFS60E-BZAA0-S01
SICK VIỆT NAM
12 tháng
.
- PERFORMANCE
Pulses per revolution 360 Measuring step 90° electronically/ppr Measuring step deviation at non binary number of lines ± 0.2° Error limits ± 0.3° Initialization time 40 ms
- INTERFACES
Communication interface Incremental Communication Interface detail HTL / Push pull Number of signal channels 6-channel
- ELECTRICAL DATA
Connection type Cable, 8-wire, universal, 1.5 m Operating current 40 mA Power consumption ≤ 0.5 W (without load) Supply voltage 10 V ... 32 V Load current ≤ 30 mA Output frequency ≤ 300 kHz Reference signal, number 1 Reference signal, position 90°, electric, logically gated with A and B Reverse polarity protection ✔ Short-circuit protection of the outputs ✔ 1) MTTFd: mean time to dangerous failure 300 years (EN ISO 13849-1) 2) - 1) Short-circuit opposite to another channel, US or GND permissable for maximum 30 s.
- 2) This product is a standard product and does not constitute a safety component as defined in the Machinery Directive. Calculation based on nominal load of components, average ambient temperature 40°C, frequency of use 8760 h/a. All electronic failures are considered hazardous. For more information, see document no. 8015532.
- MECHANICAL DATA
Mechanical design Solid shaft, face mount flange Shaft diameter 10 mm Wave length 19 mm Weight 0.3 kg Flange material Aluminum Housing material Aluminum die cast Start up torque 0.5 Ncm (+20 °C) Operating torque 0.3 Ncm (+20 °C) Permissible shaft loading radial/axial 80 N (radial)40 N (axial) Operating speed ≤ 9,000 min⁻¹ 1) Moment of inertia of the rotor 6.2 gcm² Bearing lifetime 3.6 x 10^10 revolutions Angular acceleration ≤ 500,000 rad/s² - 1) Allow for self-heating of 3.3 K per 1,000 rpm when designing the operating temperature range.
- AMBIENT DATA
EMC According to EN 61000-6-2 and EN 61000-6-3 Enclosure rating IP67, housing side, cable connection (according to IEC 60529)IP65, shaft side (according to IEC 60529) Permissible relative humidity 90 % (condensation of the optical scanning not permitted) Operating temperature range 0 °C ... +85 °C Storage temperature range –40 °C ... +100 °C, without package Resistance to shocks 50 g, 6 ms (according to EN 60068-2-27) Resistance to vibration 20 g, 10 Hz ... 2,000 Hz (according to EN 60068-2-6)
- CLASSIFICATIONS
ECl@ss 5.0 27270501 ECl@ss 5.1.4 27270501 ECl@ss 6.0 27270590 ECl@ss 6.2 27270590 ECl@ss 7.0 27270501 ECl@ss 8.0 27270501 ECl@ss 8.1 27270501 ECl@ss 9.0 27270501 ETIM 5.0 EC001486 ETIM 6.0 EC001486 UNSPSC 16.0901 41112113
