Primary brand
COGNEX
Main function
Scanner (Barcodes)
Product series / family name
DataMan 60 series
Supply voltage (DC)
4.5-24Vdc (5Vdc / 6Vdc / 12Vdc nom.)
Functions
1D / 2D Fixed-mount barcode reader / scanner (0.4Mpixel)
Up to 45 decodes per second
1D / 2D quality process control metrics
Up to 45 decodes per second
1D / 2D quality process control metrics
Design
6.2mm f/5 lns. 3-position adjustable lns.
embedded high-power illumination red LED light
infrared IR blocking filter
Bright LED aimer
embedded high-power illumination red LED light
infrared IR blocking filter
Bright LED aimer
Sensing distance
40mm
70mm
110mm
70mm
110mm
Image sensor characteristics
752x480pixels resolution (1/3" CMOS sensing)
Connection type
pigtail terminated with 15-pin D-Sub connector (RS-232)
RJ45 connector (Ethernet)
RJ45 connector (Ethernet)
Communication protocol
RS-232
Ethernet
Ethernet
Digital inputs
1 x digital input (4-26Vdc / trigger input)
1 x digital input (4-26Vdc / discrete input)
1 x digital input (4-26Vdc / discrete input)
Digital outputs
2 x digital outputs (26Vdc 25mA / Sink/Source discrete outputs)
1 x digital output (4-26Vdc / Sink/Source discrete output; TTL output; Open-collector output)
1 x digital output (4-26Vdc / Sink/Source discrete output; TTL output; Open-collector output)
Degree of protection
IP40
Ambient air temperature for operation
0...+40 °C
Power consumption
2.5 W
Technical compatibility with
1DMax
Hotbars
2DMax
Hotbars
2DMax
Benefits
Challenging 1D and 2D codes including DPM codes
High speed 1D / 2D code reading
Omnidirectional 1D barcode reading
High speed 1D / 2D code reading
Omnidirectional 1D barcode reading
Net Height (mm)
23.5 mm
Net Width (mm)
41 mm
Net Depth (mm)
53.5 mm
Ambient air temperature for storage
-10...+60 °C
Refresh rate (fps)
60fps
Type of lens
6.2mm
