DSBC-32-25-PPVA-N3 | Festo | Xilanh Festo DSBC-32-25-PPVA-N3 | Festo Vietnam | Greentech Vietnam

DSBC-32-25-PPVA-N3

Festo Vietnam | Greentech Vietnam

12 tháng

DSBC-32-25-PPVA-N3 | Festo | Xilanh Festo DSBC-32-25-PPVA-N3 | Festo Vietnam | Greentech Vietnam

Product Details

DSBC Series Profile Cylinders - Adjustable Pneumatic Cushioning

Festo DSBC series profile pneumatic cylinder offer excellent running performance and long service life. Featuring a stainless steel piston rod with external and internal thread options. An extensive range of accessories makes it possible to install the DSBC cylinders virtually anywhere.

Adjustable Pneumatic Cushioning

Adjustable PPV type cushioning cylinders absorb energy in the end positions by building up and exhausting an air cushion in a targeted fashion. This allows high levels of energy absorption while also reducing noise. The manual adjusting screw allows for fine adjustments to suit the application.

Features and Benefits

ISO 15552
Stainless steel piston rod
Wide range of variants
Long service life
Double acting

Application Information

The DSBC adjustable cushioning pneumatic cylinders are equipped with a special cushioning piston as an extension to the main piston. This relatively long cushioning piston builds up an air cushion in the connection cap before end position. This energy absorbing method makes these cylinders ideal for medium to heavy loads and high speed applications.





Festo ISO 15552 Proflie Cylinders



Specifications
Attribute Value
Manufacturer Series DSBC
Action Double
Rods Single
Bore 32mm
Stroke 25mm
VDMA Standard 24562
ISO Standard 6431, 15552
Maximum Operating Pressure 12 bar
Force at 7 bar 415 (Retracting) N @ 6 bar, 483 (Advancing) N @ 6 bar
Cushioning Type Air
Port Connection G 1/8
Dimensions 170.1 x 45 x 45mm
Test Weight 465 g @ 0 mm Stroke
Minimum Operating Temperature -20°C
Length 170.1mm
Maximum Operating Temperature +80°C
Height 45mm
Stroke Interval Weight 27 g @ 10 mm Stroke
CAD Drawing 3D CAD Model
Width 45mm
