DT8121X | Dotech DT8121X | Màn hình hiển thị Dotech DT8121X | Touch Monitor | Dotech Vietnam
DT8121X
Dotech Vietnam
[DT8121X] 12.1-inch Touch Monitor
12.1" TFT LCD
800 x 600
.
_.jpg)
| DT8121X | ||
| Display | Screen size | 12.1" TFT LCD |
| Resolution | 800 x 600 | |
| Backlight type | CCFLx2 | |
| Backlight life time | 50,000 hr | |
| Power | Input power | 24 ±10% VDC |
| Power consumption | 1.25A@24VDC | |
| Specification | Panel cutout (W x H) | 305x231mm |
| Weight (kg) | Approx 2.1kg | |
| Operation | CE | Compilies with EN 55022:1998+A1: 2000+A2:2003, EN 55024:1998+A1:2001+A2:2003 standards |
| UL | E248297 | |
| Vibration Endurance | 10 to 25 Hz (X,Y,Z direction 2G 30minutes) | |
| Protection structure | IP65 front panel (O ring seal) | |
| Storage temperature | -20°~60°C (-4°~140°F) | |
| Working temperature | 0°~50°C (32°~122°F) | |
| Operating humdity | 10-90% RH (non-condense) | |
