E3ZM-CT61 | Omron E3ZM-CT61 | Cảm biến quang |Compact Photoelectric Sensor with Built-in Amplifier
E3ZM-CT61 2M
Omron Vietnam | Greentech Vietnam
.
Through-beam, Sensing distance 15m, Light-ON/Dark-ON selectable, NPN output, Pre-wired models(2m)
| Sensing method | Through-beam |
|---|---|
| Sensing distance | 0m to 15m |
| Light source | Infrared LED |
| Control output (Output type) | NPN open collector output |
| Connection method | Pre-wired models （Cable length: 2 m） |
| Sensing method | Through-beam |
|---|---|
| Sensing distance | 0m to 15m |
| Standard sensing object | Opaque 12 mm dia. Min. |
| Directional angle | Emitter: 3 to 15 DEGReceiver: 3 to 15 DEG |
| Light source | Infrared LED |
| Power supply voltage | 10 to 30 VDC (ripple (p-p) 10% included) |
| Current consumption | Emitter: 20 mA DC Max.Receiver: 20 mA DC Max. |
| Control output (Output type) | NPN open collector output |
| Control output (Load current) | 0 to 100 mA |
| Control output (Residual voltage) | (DC) 2 V Max. (Load current 100mA Max.) |
| Operation mode | Light-ON/Dark-ON selectable |
| Load power supply voltage | 30 VDC Max. |
| Protective circuit | Surge suppressorOutput short-circuit protectionPower supply reverse polarity protection |
| Response time | 1 ms Max. |
| Sensitivity setting | Single-turn adjustment |
| Ambient illuminance | Incandescent lamp: 3000 lux Max., Sunlight: 10000 lux Max. |
| Ambient temperature | Operating: -25 to 55℃Storage: -40 to 70℃(with no icing or condensation) |
| Ambient humidity | Operating: 35 to 85%Storage: 35 to 95%(with no icing or condensation) |
| Insulation resistance | 20 MOhm Min. at 500 VDC between charged parts and the case |
| Dielectric strength | 1000 VAC at 50/60 Hz for 1 minute between charged parts and the case |
| Vibration resistance | 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock resistance | 500 m/s**2 for 3 times each in X, Y, and Z directions |
| Degree of protection | IEC60529: IEC: IP67, DIN 40050-9: IP69KCompany standard: Oil-proof |
| Connection method | Pre-wired models （Cable length: 2 m） |
| Indicator | Operation indicator (yellow), Stability indicator (green), Power indicator (green) |
| Tightening torque | 0.5 N・m Max. (with M3 screw) |
| Material (case) | SUS316L |
| Material (lens) | Methacrylate resin |
| Accessories | Instruction manual |
Short distance version
