AZM200CC-T-1P2P | Schmersal | Công tắc, cảm biến cửa an toàn | Schmersal Việt Nam

(0 đánh giá)

AZM200CC-T-1P2P

Schmersal Vietnam | Greentech Vietnam

12 tháng

• Thermoplastic enclosure • Guard locking monitored • Electronic contact-free, coded system • Max. length of the sensor chain 200 m • Self-monitoring series-wiring of 31 sensors • 3 LEDs to show operating conditions • Sensor technology permits an offset between actuator and interlock of ± 5 mm vertically and ± 3 mm horizontally • Intelligent diagnosis • Manual release

Ordering details

Product type description AZM 200CC-T-1P2P
Article number 101179701
EAN code 4030661312699
eCl@ss 27-27-26-03

Approval

Approval  TÜV
 USA/CAN

Classification

Interlocking function:
Standards EN ISO 13849-1, IEC 61508, IEC 60947-5-3
PL bis e
Control category bis 4
PFH 4.0 x 10-9/h
PFD value 1.0 x 10−4
SIL bis 3
Mission time 20 Years
Classification PDF-M
Guard locking function:
Standards EN ISO 13849-1, IEC 61508, IEC 60947-5-3
PL up d
Control category up 2
PFH value 2.5 x 10−9/h
PFD value 2.2 x 10−4
SIL up 2
Mission time 20 Years

Global Properties

Product name AZM 200
Standards EN 60947-5-1, IEC 61508, EN ISO 13849-1, EN ISO 13849-1
Compliance with the Directives (Y/N)  Yes
Suitable for safety functions (Y/N) Yes
Protection rating II
Series-wiring up to 31 components
Length of the sensor chain max. 200 m
Active principle inductive
Duty cycle 100 %
Materials
- Material of the housings Plastic, glass-fibre reinforced thermoplastic
Housing coating None
Weight 536 g
Guard locking monitored (Y/N) Yes
Actuator monitored (Y/N) No
Idle assignable pushbutton and LED (Y/N) No
Reaction time ≤ 60 ms
Duration of risk > 120 ms
Time to readiness 4000 ms
Recommended actuator AZ/AZM 200-B1

Mechanical data

Design of electrical connection Spring pulley connection
Cable section
- Min. Cable section 0,25 mm²
- Max. Cable section 1.5 mm²
AWG-Number 23 - 15
Mechanical life ≥ 1.000.000 operations
notice All indications about the cable section are including the conductor ferrules.
restistance to shock 30 g / 11 ms
Resistance to vibration 10 ... 55 Hz, Amplitude 1 mm
Emergency unlocking device (Y/N) No
Manual release (Y/N) Yes
Emergency release (Y/N) No
Latching force 30 N
Clamping force F 2000 N
Max. Actuating speed ≤ 0,2 m/s

Ambient conditions

Ambient temperature
- Min. environmental temperature −25 °C
- Max. environmental temperature +60 °C
Storage and transport temperature
- Min. Storage and transport temperature −25 °C
- Max. Storage and transport temperature +85 °C
Relative humidity 30% ... 95%
- non-condensing
Protection class IP67 to IEC/EN 60529
Air clearances and creepage distances To IEC/EN 60664-1
- Rated impulse withstand voltage Uimp 0,8 kV
- Overvoltage category III
- Degree of pollution 3

Electrical data

Number of auxiliary contacts 0 piece
Number of safety contacts 2 piece
Cross circuit/short circuit recognition possible (Y/N) Yes
Power to unlock Yes
Power to lock No
Supply voltage UB
- Min. supply voltage 20.4 VDC
- Max. supply voltage 26.4 VDC
Switch frequency 1 Hz
Rated insulation voltage Ui 32 VDC
Operating current Ie 1.2 A
Utilisation category DC-12, DC-13
No-load current I0 0,6 A
Device insulation ≤ 4 A if used in accordance with UL 508

Electrical data - Safety inputs

Safety inputs X1 and X2
Rated operating voltage Ue - 3 V ... 5 V (Low)
15 V ... 30 V (High)
Operating current Ie > 2 mA / 24 V

Electrical data - Safety outputs

Safety outputs Y1 and Y2
Fuse rating short-circuit proof, p-type
Rated operating voltage 0 V ... 4 V under Supply voltage UB
Residual current Ir ≤ 0,5 mA
Operating current Ie 0,25 A
Utilisation category DC-12, DC-13

Electrical data - Diagnostic output

Serial diagnostics (Y/N) No
Fuse rating p-type, short-circuit proof
Operating current Ie 0,05 A
Utilisation category DC-12, DC-13
Wiring capacitance for serial diagnostics -
diagnostic signals guard door closed
Operating principle of the diagnostic output The short-circuit proof diagnostic output OUT can be used for central visualisation or control tasks, e.g. in a PLC.
notice The diagnostic output is not a safety-relevant output!

Electrical data - Solenoid control IN

Rated operating voltage Ue - 3 V ... 5 V (Low)
15 V ... 30 V (High)
Operating current Ie typically 10 mA / 24 V, dynamically 20 mA

LED switching conditions display

LED switching conditions display (Y/N) Yes
LED switching conditions display
- Supply voltage UB green LED
- switching condition yellow LED
- Error functional defect red LED

ATEX

Explosion protection categories for gases None
Explosion protected category for dusts None

Dimensions

Dimensions of the sensor
- Width of sensor 40 mm
- Height of sensor 220 mm
- Length of sensor 50 mm

notice

As lons as the actuating unit remains inserted in the solenoid interlock, the unlocked safety guard can be relocked. The safety outputs then will be enabled again; opening the safety guard therefore is not required.

Included in delivery

Included in delivery AZM 200
Triangular key
Actuators must be ordered separately.

K.A. Schmersal GmbH & Co. KG, Möddinghofe 30, D-42279 Wuppertal
The data and values have been checked throroughly. Technical modifications and errors excepted.
Generiert am 13.08.2017 - 17:00:41h Kasbase 3.2.7.F.64I
